Technical Specifications
| Model No.
|
P/N
|
| VS19063
|
M2W
|
| Item
|
Category
|
Specifications
|
| Projector
|
Type
|
0.45” WXGA, LED
|
| Display Size
|
24”~150”
|
| Throw Distance
|
0.50m - 3.87 m (100”@2.58 m)
|
| Lens
|
F=1.7, f=11.96 mm
|
| Optical Zoom
|
Fixed
|
| Lamp Type
|
RGB LED
|
| Light Source Life
(Normal)
|
up to 30,000 hours
|
| Display Color
|
1.07 Billion Colors
|
| Keystone
|
-/+ 40 (Vertical & Horizontal)
|
| Input Signal
|
HDMI
|
fh: 30K~97KHz, fv:24~85Hz
|
| Resolution
|
Native
|
1280 x 800
|
| Support
|
VGA (640 x 480) to Full HD (1920 x 1080)
|
| Local Storage
|
Total
|
16 GB
|
| Available
|
10 GB
|
| Input
|
HDMI
|
1 (HDMI 1.4, HDCP 1.4)
|
| SD Card
|
Micro SD (Supports up to 256 GB, SDXC)
|
| USB Type-C
|
1 (5V/0.5A)
|
| USB Type-A
|
1 USB 2.0 Reader
|
| Wi-Fi Input
|
1 (5G)
|
| Output
|
Audio Out (3.5 mm)
|
1
|
| Bluetooth Output
|
1 (BT 4.2/Audio Out)
|
| Speaker
|
3W Cube x 2 (Full range x2)
|
| USB Type-A (Power)
|
1 (USB 2.0, 5V/1.5A, share with reader)
|
| Power Adapter[1]
|
Input Voltage
|
DC IN 100-240V, 50/60 Hz (auto switch)
|
| Operating Conditions
|
Temperature
|
0°C to 40°C (32°F to 104°F)
|
| Humidity
|
0% to 90% (non-condensing)
|
| Dimensions
|
Physical
(W x H x D)
|
225 x 225 x 57 mm
(8.9” x 8.9” x 2.2”)
|
| Weight
|
Physical
|
1.35 kg (2.98 lbs)
|
| Power Consumption
|
On
|
71W (Typical)
|
| Off
|
< 0.5W (Standby)
|
- ↑ Please use the power adapter from ViewSonic® or an authorized source only.
Projector Dimensions
225 mm (W) x 225 mm (H) x 52 mm(D)
Timing Chart
HDMI Video Timing
| Timing
|
Resolution
|
Horizontal Frequency (KHz)
|
Vertical Frequency (Hz)
|
Dot Clock Frequency (MHz)
|
| 480i
|
720(1440) x 480
|
15.73
|
59.94
|
27
|
| 480p
|
720 x 480
|
31.47
|
59.94
|
27
|
| 576i
|
720(1440) x 576
|
15.63
|
50
|
27
|
| 576p
|
720 x 576
|
31.25
|
50
|
27
|
| 720/50p
|
1280 x 720
|
37.5
|
50
|
74.25
|
| 720/60p
|
1280 x 720
|
45
|
60
|
74.25
|
| 1080/50i
|
1920 x 1080
|
28.13
|
50
|
74.25
|
| 1080/60i
|
1920 x 1080
|
33.75
|
60
|
74.25
|
| 1080/24p
|
1920 x 1080
|
27
|
24
|
74.25
|
| 1080/50p
|
1920 x 1080
|
56.25
|
50
|
148.5
|
| 1080/60p
|
1920 x 1080
|
67.5
|
60
|
148.5
|
HDMI PC
| Resolution
|
Refresh Rate (Hz)
|
Horizontal Frequency (KHz)
|
Dot Clock Frequency (MHz)
|
| 640 x 480
|
59.94
|
31.469
|
25.175
|
| 72.809
|
37.861
|
31.5
|
| 75
|
37.5
|
31.5
|
| 85.008
|
43.269
|
36
|
| 720 x 400
|
70.087
|
31.469
|
28.3221
|
| 800 x 600
|
60.317
|
37.879
|
40
|
| 72.188
|
48.077
|
50
|
| 75
|
46.875
|
49.5
|
| 85.061
|
53.674
|
56.25
|
| 119.854
|
77.425
|
83
|
| 1024 x 576
|
60
|
35.82
|
46.966
|
| 1024 x 600
|
64.995
|
41.467
|
51.419
|
| 1024 x 768
|
60.004
|
48.363
|
65
|
| 70.069
|
56.476
|
75
|
| 75.029
|
60.023
|
78.75
|
| 84.997
|
68.667
|
94.5
|
| 119.989
|
97.441
|
115.5
|
| 1152 x 864
|
75
|
67.5
|
108
|
| 1280 x 720
|
60
|
45
|
74.25
|
| 1280 x 768
|
59.87
|
47.776
|
79.5
|
| 1280 x 800
|
59.81
|
49.702
|
83.5
|
| 74.934
|
62.795
|
106.5
|
| 84.88
|
71.554
|
122.5
|
| 1280 x 960
|
60
|
60
|
108
|
| 85.002
|
85.938
|
148.5
|
| 1280 x 1024
|
60.02
|
63.981
|
108
|
| 75.025
|
79.976
|
135
|
| 85.024
|
91.146
|
157.5
|
| 1360 x 768
|
60.015
|
47.712
|
85.5
|
| 1400 x 1050
|
59.978
|
65.317
|
121.75
|
| 1440 x 900
|
59.887
|
55.935
|
106.5
|
| 1600 x 1200
|
60
|
75
|
162
|
| 1680 x 1050
|
59.954
|
65.29
|
146.25
|
| 1920 x 1080 (VESA)
|
60
|
67.5
|
148.5
|
| 640 x 480 @ 67Hz
|
66.667
|
35
|
30.24
|
| 832 x 624 @ 75Hz
|
74.546
|
49.722
|
57.28
|
| 1024 x 768 @ 75Hz
|
75.02
|
60.241
|
80
|
| 1152 x 870 @ 75Hz
|
75.06
|
68.68
|
100
|
USB C
| Resolution
|
Refresh Rate (Hz)
|
Horizontal Frequency (KHz)
|
Dot Clock Frequency (MHz)
|
| 480i
|
59.94
|
15.73
|
27
|
| 480p
|
59.94
|
31.47
|
27
|
| 576i
|
50
|
15.63
|
27
|
| 576p
|
50
|
31.25
|
27
|
| 720/50p
|
50
|
37.5
|
74.25
|
| 720/60p
|
60
|
45
|
74.25
|
| 1080/50i
|
50
|
28.13
|
74.25
|
| 1080/60i
|
60
|
33.75
|
74.25
|
| 1080/24p
|
24
|
27
|
74.25
|
| 1080/50p
|
50
|
56.25
|
148.5
|
| 1080/60p
|
60
|
67.5
|
148.5
|
LED Indicators
| Light
|
Status and Description
|
|
|
|
|
Power
|
| Red
|
Stand-by mode (5 sec.) (< 0.5W)
|
| Green
|
Power On
|
