M1 mini Plus Introduction

From ViewSonic User Guide Database
Jump to navigation Jump to search

Features

  • Short throw lens design allows for a projected 39” screen size from only 1 meter away.
  • Auto V. keystone to correct a distorted image automatically.
  • Excellent audio performance by JBL.
  • Instant on/off and great colors.
  • Swappable color top plates and flexible angle adjustment.
  • Multi-language On-Screen Display (OSD) menus.
  • Embedded battery for easy outdoor projection.
  • User-friendly UI design for easy navigation.
  • LED light source with excellent light source life (30,000 hours).
  • Color modes for every occasion.
  • 8 GB internal storage (Max. 4 GB available for user storage).
  • Bluetooth speaker, Bluetooth out, and Screen Mirroring features.
NOTE: The apparent brightness of the projected image will vary depending on the ambient lighting conditions, selected input signal contrast/brightness settings, and projection distance.

Package Contents

  1. The CR2032 battery is inside the remote control.

Projector Overview

Number Item
1 Vent
2 Smart Stand
3 IR Receiver
4 Focus Ring
5 DC IN (USB-C Port)
6 USB Type A Port
7 Speaker
8 Lens
9 Top Plate
10 Power Switch
11 LED Indicator
12 IR Receiver
13 Lanyard Attachment Point
14 Power Switch
15 HDMI Port
