Package Contents

Item	Quantity	Note
Cabinet Sections	6 sections total	One (1) left, four (4) Middle, and one (1) Right.
System Control Box (Left and Right sides)	2 sides
Quick Start Guide	1
LED Modules	144 modules	ONLY the American market will include two (2) spare modules.
Remote Control	1
Screws	20 x M6x10mm (1) 32 x M6x50mm Expansion (2) 32 x TA6x30mm (3) 24 x M6x16mm (4) 15 x KM3x6mm (5)
Hex Tool	1
System Control Box Covers (Left, Middle, and Right sides)	3
Wall Mounting Brackets	4
Vacuum Suction Tool	1	ONLY included in the American market.
Anti-Static Glove	2 pairs
USB-A to USB-C Cable (5m)	1

NOTE:

This product is packed in an air transport box.

Due to the size and weight, it is recommended that two or more people handle it.

The base stand is an optional accessory and will be sold separately.

Product Overview

Front Panel

Rear Panel

I/O Control Panel

Number	Port	Description
1	HDMI OUT	Connect to devices with HDMI input function. Supports 1080p and 4K@60Hz.
2	USB 3.0	Connect USB devices such as hard disks, keyboard, mouse, etc. Automatically switches between PC and Android.
3	TOUCH 1	Touch signal output to external PC Network signal output to external PC when the Embedded Player has LAN port input. After connection (with external PC), the external PC’s audio can be played through the ViewBoard, and the external PC’s audio can be controlled by the audio button of the ViewBoard. After connection (with external PC), the device connected to the USB 3.0 port can be directly used by an external PC.
4	HDMI IN 1/2	High definition input; connect to PC with HDMI output, set-top box, or other video device.
5	HDMI IN 3	High definition input; connect to PC with HDMI output, set-top box, or other video device.
6	TOUCH 2	Touch signal output to external PC Network signal output to external PC when the Embedded Player has LAN port input. After connection (with external PC), the external PC’s audio can be played through the ViewBoard, and the external PC’s audio can be controlled by the audio button of the ViewBoard. After connection (with external PC), the device connected to the USB 3.0 port can be directly used by an external PC.
7	Wi-Fi Module Slot	Slot for adding optional Wi-Fi module.
8	VGA	External computer video input.
9	AUDIO IN	External computer audio input.
10	SPDIF	Multichannel sound via optical signals.
11	RS-232	Serial interface; used for mutual transfer of data between devices.
12	AUDIO OUT	Audio output to an external speaker.
13	LAN	Standard RJ45 (10M/100M/1G for PC; 10M/100M for Android) Internet connection interface.
