VG2740V Specifications

    From ViewSonic User Guide Database

    Technical Specifications

    Model No. P/N
    VS18629 VG2740V
    Item Category Specifications
    LCD Type IPS, a-si TFT Active Matrix,

    1920 x 1080 LCD 0.3114 mm x 0.3114 mm pixel pitch

    Display Size 68.5 cm (27" viewable)
    Color Filter RGB vertical stripe
    Glass Surface Anti-Glare (Haze 25%), Hard Coating (3H)
    Input Signal Video Sync Separate Sync
    VGA: fh:24-82 Khz, fv:50-75 Hz

    TMDS digital (100 Ω)

    HDMI(v1.4): fh:24-82 Khz, fv:24-75 Hz

    PCI-E

    DisplayPort(v1.2): fh:15-82 Khz, fv:24-75 Hz
    Audio Speaker 2W x 2
    Compatibility PC up to 1920 x 1080
    Macintosh up to 1920 x 1080
    Recommended 1920 x 1080 @ 60Hz
    Resolution[1] Supported
    • 1920 x 1080 @ 50, 60Hz
    • 1680 x 1050 @ 60Hz
    • 1600 x 1200 @ 60Hz
    • 1600 x 900 @ 60Hz
    • 1440 x 900 @ 60, 75Hz
    • 1440 x 576 @ 50Hz
    • 1400 x 1050 @ 60, 75Hz
    • 1366 x 768 @ 60Hz
    • 1360 x 768 @ 60Hz
    • 1280 x 1024 @ 50, 60, 75Hz
    • 1280 x 960 @ 50, 60, 75Hz
    • 1280 x 800 @ 60, 75Hz
    • 1280 x 768 @ 50, 60, 75Hz
    • 1280 x 720 @ 50, 60Hz
    • 1152 x 900 @ 66Hz
    • 1152 x 870 @ 75Hz
    • 1152 x 864 @ 60, 75Hz
    • 1024 x 768 @ 50, 60, 70, 72, 75Hz
    • 1024 x 600 @ 60Hz
    • 848 x 480 @ 60Hz
    • 832 x 624 @ 75Hz
    • 800 x 600 @ 56, 60, 72, 75Hz
    • 720 x 576 @ 50Hz
    • 720 x 480 @ 60Hz
    • 720 x 400 @ 70Hz
    • 640 x 480 @ 50, 60, 66, 72, 75Hz
    • 640 x 400 @ 60, 70Hz
    • 640 x 350 @ 70Hz
    Power Adapter[2] Input Voltage AC 100-240V, 50/60Hz (auto switch)
    Display Area Full Scan

    (H x V)

    597.8 x 336.3 mm

    (23.53” x 13.24”)

    Operating Conditons Temperature 0° C to 40° C (32° F to 104° F)
    Humidity 20% to 90% (non-condensing)
    Altitude 16,404 feet (4.9 km)
    Storage Conditions Temperature -20° C to 60° C (-4° F to 140° F)
    Humidity 5% to 90% (non-condensing)
    Altitude 40, 000 feet (12.1 km)
    Dimensions Physical

    (W x H x D)

    620.69 x 557.04 x 205.51 mm

    (24.44” x 21.93” x 8.09”)

    Wall Mount Dimensions 100 x 100 mm
    Weight Physical 7.2 kg (15.87 lbs)
    Power Saving Modes On 26.14W (Typical) (Blue LED)

    32.5W (Max[3]) (Blue LED)

    Off < 0.3W (Max)
    1. Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display.
    2. Please use the power adapter from ViewSonic® or an authorized source only.
    3. Maximum power consumption with max luminance, and USB/Speaker active. Without USB C power delivery.

    Product Upgradeability and Repairability

    The following is a list of hardware features available for at least 5 years after the sale of the product. Upgradable Repairable Replaceable
    Main Processor(s) or SOC No No Yes
    Memory N/A N/A N/A
    HDD N/A N/A N/A
    Wireless Network Capability N/A N/A N/A
    Graphics Card N/A N/A N/A
    Rechargeable Battery N/A N/A N/A
    Fan Assembly N/A N/A N/A
    Camera N/A N/A N/A
    Fingerprint Reader N/A N/A N/A
    Display Assembly No No Yes
    Keyboard N/A N/A N/A
    Internal Power Supply No No Yes
    NOTE: N/A = Not applicable for the product.
