LD163-181 Remote Control

Remote Control Overview

Remote Control

Number	Description
1	Power On/Off
2	Input source selection
3	Mute/Unmute
4	Play/Pause content
5	Move content forwards and backwards
6	Increase/decrease the volume level
7	Switch to a blank, black screen
8	Enter the Settings menu
9	Directional buttons
10	Back to the Home Screen
11	Return to previous page
12	Numeric input buttons
13	Delete key for text input
14	Input key for symbols (e.g. periods)

Remote Control Receiver Range

The operating range of the remote control is shown here. It has an effective range of 20 feet (6 meters), 30° degrees left and right. Ensure there is nothing obstructing the remote control’s signal to the receiver.

Inserting Remote Control Batteries

The remote control is powered by two 1.5v "AAA" batteries.

To insert batteries into the remote control:

1. Remove the cover on the rear of the remote control.
2. Insert two “AAA” batteries, ensuring the “+” symbol on the battery matches the “+” on the battery post.
3. Replace the cover by aligning it with the slot on the remote control and snapping the latch shut.

Warning: There is a risk of explosion if batteries are installed with incorrect polarity.

NOTE:

• It is recommended that you do not mix battery types.
• Avoid exposure to heat or steam.
• Do not allow water or other liquids to splash on the remote control. If the remote control becomes wet, wipe it dry immediately.
• Always dispose of old batteries in an environmentally friendly way. Contact your local government for more information on how to dispose of batteries safely.
