IFP75G1 Introduction

Package Contents

Note: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.

•
  HDMI Cable
  (3 m)
•
  Power Cord
  (ship by region)
•
  USB Touch Cable (3 m)
•
  Remote Control
•
  AAA Battery x 2
•
  Compliance Statement
•
  Quick Start Guide
•
  Touch Pen x 2
•
  Replacement Pen Nib x 4
•
  RS-232 Adapter
•
  Clamp x 5
•
  Wall Mount Screws
•
  Wall Mount Screws (M8 x 25mm x 4)
•
  Camera Plate

Wall Mount Kit Specifications (VESA)

Model	VESA Spec. (A x B)	Standard Screw (C x D)	Quantity
IFP75G1	800 x 400 mm	M8 x 25 mm	4

NOTE:

• Please follow the instructions in the wall mount installation guide to install your wall mount (check here) or mobile mount bracket (check the video here). If attaching to other building materials, please contact your nearest dealer.
• Do not use screws that are longer than the standard dimension, as they may cause damage to the inside of the display.

Product Overview

Front Panel

Rear Panel

Control Panel

Number	Item	Description
1		Decrease screen brightness.
2		Increase screen brightness.
3		Decrease the volume.
4		Increase the volume.
5		Disable/Enable the touch screen.
6		Launch the Menu system.
7		Power indicator light. Press to turn ON the device. Press to turn OFF/ON the display backlight only. Press and hold to turn OFF the device.

I/O Panels

Front I/O

Overview

Front I/O

Number	Port	Description
1	USB	USB Type A input USB 3.0 standard Connect USB devices such as hard disks, keyboard, mouse, etc. Automatically switches between the external computer and ViewBoard
2	USB	USB Type A input USB 2.0 standard
3		Remote control receiver
4		Ambient Light Sensor

Rear and Side I/O

Overview

Rear I/O

Number	Port	Description
1	USB	USB Type A input USB 2.0 standard
2	RS-232	Serial interface; used for mutual transfer of data between devices
3	LAN	Standard RJ45 (10M/100M/1000M) Internet connection interface. Features hub support for network sharing.

Side I/O

Number	Port	Description
1	VGA	External computer video input
2	AUDIO OUT	Audio output to an external speaker/headset
3	AUDIO IN	External computer audio input
4	USB	USB Type A input USB 3.0 standard Connect USB devices such as hard disks, keyboard, mouse, etc.
5	TOUCH 1	USB Type B Touch signal output to external computer After connection (with an external computer), the device connected to the USB port can directly be used by the external computer NOTE: Pairs with HDMI 1 port.
6	HDMI 1	HDMI input Connect to a computer with HDMI output, set-top box, or other video device Supports 4K display; HDMI v. 2.0; CEC; ARC
7	HDMI 2	HDMI input Connect to a computer with HDMI output, set-top box, or other video device Supports 4K display; HDMI v. 2.0; CEC; ARC
8	HDMI 3	HDMI input Connect to a computer with HDMI output, set-top box, or other video device Supports 4K display; HDMI v. 2.0; CEC; ARC
9	TOUCH 2	USB Type B Touch signal output to external computer After connection (with an external computer), the device connected to the USB port can directly be used by the external computer NOTE: Pairs with HDMI 2 and HDMI 3 ports.
10		C Type Port input USB 3.0 standard Supports DP v. 1.2 with audio, video, and touch Supports power charge up to 65W. Power charge supported: 5V/3A, 9V/3A, 15V/3A, 20V/3.25A
