Technical Specifications

Model No. P/N
VS18302 VG2756-2K
Item Category Specifications
LCD Type a-si TFT LCD,

Active Matrix 2560 x 1440 0.233 mm x 0.233 mm pixel pitch

Display Size 68.6 cm, 27"
Color Filter RGB vertical stripe
Glass Surface Anti-Glare type, 3H hard coating, Haze 25
Input Signal Video Sync TMDS digital (100 Ω)

fh:15-90 Khz, fv:49-75 Hz

Compatibility PC up to 2560 x 1440
Macintosh up to 2560 x 1440
Recommended 2560 x 1440 @ 60Hz
Resolution[1] Supported
  • 2560 x 1440 @ 60Hz
  • 1920 x 1200 @ 60Hz
  • 1920 x 1080 @ 60Hz
  • 1680 x 1050 @ 60Hz
  • 1440 x 900 @ 60Hz
  • 1280 x 1024 @ 60, 75Hz
  • 1024 x 768 @ 60, 70, 75Hz
  • 720 x 400 @ 70Hz
  • 640 x 480 @ 60, 72, 75Hz
Power Adapter[2] Input Voltage AC 100-240V, 50/60Hz (auto switch)
Display Area Full Scan

(H x V)

596.74 x 335.66 mm

(23.49” x 13.21”)

Operating Conditons Temperature 0° C to 40° C (32° F to 104° F)
Humidity 20% to 90% (non-condensing)
Altitude 16,404 feet (4.9 km)
Storage Conditions Temperature -20° C to 60° C (-4° F to 140° F)
Humidity 5% to 90% (non-condensing)
Altitude 40, 000 feet (12.1 km)
Dimensions Physical

(W x H x D)

611.73 x 533.24 x 202.18 mm

(24.08” x 20.99” x 7.97”)

Wall Mount Dimensions 100 x 100 mm
Weight Physical 6.9 kg (15.21 lbs)
Power Saving Modes On 26.35W (Typical) (Blue LED)

67.03W (Max[3]) (Blue LED)

Off < 0.3W (Max)
  1. Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display.
  2. Please use the power adapter from ViewSonic® or an authorized source only.
  3. Maximum power consumption with max luminance, and USB/Speaker active. Without USB C power delivery.

Product Upgradeability and Repairability

The following is a list of hardware features available for at least 5 years after the sale of the product. Upgradable Repairable Replaceable
Main Processor(s) or SOC No No Yes
Memory N/A N/A N/A
HDD N/A N/A N/A
Wireless Network Capability N/A N/A N/A
Graphics Card N/A N/A N/A
Rechargeable Battery N/A N/A N/A
Fan Assembly N/A N/A N/A
Camera N/A N/A N/A
Fingerprint Reader N/A N/A N/A
Display Assembly No No Yes
Keyboard N/A N/A N/A
Internal Power Supply No No Yes
NOTE: N/A = Not applicable for the product.
