Maintenance Tools

Safety Precautions

Vacuum Suction Tool (LED Module Maintenance Tool)

Dimensions

Charging the Battery

Overview

Item	Description
Start Buttom	Start or stop the suction force.
Regulating Valve	Adjust the suction force level.
Handle	Pick up and hold the tool from here.
Charging Port	Port for charging the battery.
Power Switch	Turn the tool on or off.
LED Module Contact Silicone	Soft contact surface for removing the LED modules.
Power Display	Indicates how much battery power is remaining.

Specifications

Item	Description
Model	LD-MK-003
Product Dimension	148 x 125 x 150 mm
	5.83” x 4.92” x 5.91”
Weight	0.9 kg
	1.98 lb
Working Duration	18 minutes
Operating Relative Humidity	15%~85% (non-condensing)
Operating Temperature	-20° C to 45° C
	-4° F to 113° F

System Control Box Maintenance Tool

Dimensions

Specifications

Item	Description
Model	LD-MK-004
Product Dimension	145.1 x 125.1 x 62.3 mm
	5.71” x 4.93”x 2.45”
Weight	0.5 kg
	1.10 lb
