Safety Precautions
Vacuum Suction Tool (LED Module Maintenance Tool)
Dimensions
Charging the Battery
Overview
| Item
|
Description
|
| Start Buttom
|
Start or stop the suction force.
|
| Regulating Valve
|
Adjust the suction force level.
|
| Handle
|
Pick up and hold the tool from here.
|
| Charging Port
|
Port for charging the battery.
|
| Power Switch
|
Turn the tool on or off.
|
| LED Module Contact Silicone
|
Soft contact surface for removing the LED modules.
|
| Power Display
|
Indicates how much battery power is remaining.
|
Specifications
| Item
|
Description
|
| Model
|
LD-MK-003
|
| Product Dimension
|
148 x 125 x 150 mm
|
| 5.83” x 4.92” x 5.91”
|
| Weight
|
0.9 kg
|
| 1.98 lb
|
| Working Duration
|
18 minutes
|
| Operating Relative Humidity
|
15%~85% (non-condensing)
|
| Operating Temperature
|
-20° C to 45° C
|
| -4° F to 113° F
|
System Control Box Maintenance Tool
Dimensions
Specifications
| Item
|
Description
|
| Model
|
LD-MK-004
|
| Product Dimension
|
145.1 x 125.1 x 62.3 mm
|
| 5.71” x 4.93”x 2.45”
|
| Weight
|
0.5 kg
|
| 1.10 lb
|
