Technical Specifications

Model No. P/N
VS17984 VX2405-P-MHD
Item Category Specifications
LCD Type TFT Active Matrix 1920 x 1080 LCD,

0.2745 mm x 0.2745 mm pixel pitch

Display Size 60.5 cm, 24" (23.8" viewable)
Color Filter RGB vertical stripe
Glass Surface Anti-Glare type, 3H hard coating
Input Signal Video Sync TMDS digital (100 Ω)
HDMI: fh:30-180 kHz, fv:48-144 Hz
DisplayPort: fh:30-180 kHz, fv:48-144 Hz
Compatibility PC up to 1920 x 1080
Macintosh up to 1920 x 1080
Recommended 1920 x 1080 @ 144Hz
Resolution[1] Supported
  • 1920 x 1080 @ 50, 60, 120, 144Hz
  • 1680 x 1050 @ 60Hz
  • 1600 x 1200 @ 60Hz
  • 1600 x 900 @ 60Hz
  • 1440 x 900 @ 60, 75Hz
  • 1440 x 576 @ 50Hz
  • 1400 x 1050 @ 60, 75Hz
  • 1366 x 768 @ 60Hz
  • 1360 x 768 @ 60Hz
  • 1280 x 1024 @ 50, 60, 75Hz
  • 1280 x 960 @ 50, 60, 75Hz
  • 1280 x 800 @ 60, 75Hz
  • 1280 x 768 @ 50, 60, 75Hz
  • 1280 x 720 @ 60Hz
  • 1152 x 900 @ 66Hz
  • 1152 x 870 @ 75Hz
  • 1152 x 864 @ 60, 75Hz
  • 1024 x 768 @ 50, 60, 70, 72, 75Hz
  • 1024 x 600 @ 60Hz
  • 848 x 480 @ 60Hz
  • 832 x 624 @ 75Hz
  • 800 x 600 @ 56, 60, 72, 75Hz
  • 720 x 576 @ 50Hz
  • 720 x 480 @ 60Hz
  • 720 x 400 @ 70Hz
  • 640 x 480 @ 50, 60, 66, 72, 75Hz
  • 640 x 400 @ 60, 70Hz
  • 640 x 350 @ 70Hz
Power Adapter[2] Input Voltage AC 100-240V, 50/60Hz (auto switch)
Display Area Full Scan (H x V) 527.04 x 296.46 mm

(20.74” x 11.67”)

Operating Conditons Temperature 0° C to 40° C (32° F to 104° F)
Humidity 20% to 90% (non-condensing)
Altitude 16,404 feet (5 km)
Storage Conditions Temperature -20° C to 60° C (-4° F to 140° F)
Humidity 10% to 90% (non-condensing)
Altitude 40, 000 feet (12.1 km)
Dimensions Physical

(W x H x D)

539.52 x 409.72 x 189.52 mm

(21.24” x 16.13” x 7.46”)

Weight Physical 3.5 kg (7.7 lbs)
Power Saving Modes On[3] Without Audio: 21W (Typical); With Audio: 24W (Typical)
Off < 0.3W
  1. Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display.
  2. Please use the power adapter from ViewSonic® or an authorized source only.
  3. The test condition follows EEI standards.
