Technical Specifications

Model No. P/N
VS18172 VG1655
Item Category Specifications
LCD Type TFT, Active Matrix 1920 x 1080 LCD,

0.1792 mm x 0.1792 mm pixel pitch

Display Size 39.6 cm, 16" (15.6" viewable)
Color Filter RGB vertical stripe
Glass Surface Anti-Glare type, 3H hard coating
Input Signal Video Sync TMDS digital (100 Ω)

HDMI(v 1.4): fh:15-82 Khz, fv:50-75 Hz

Micro-Packet

Type C: fh:15-82 Khz, fv:50-75 Hz

Compatibility PC up to 1920 x 1080
Macintosh up to 1920 x 1080
Recommended 1920 x 1080 @ 60Hz
Resolution[1] Supported
  • 1920 x 1080 @ 50, 60Hz
  • 1680 x 1050 @ 60Hz
  • 1600 x 1200 @ 60Hz
  • 1600 x 900 @ 60Hz
  • 1440 x 900 @ 60, 75Hz
  • 1400 x 1050 @ 60Hz
  • 1366 x 768 @ 60Hz
  • 1360 x 768 @ 60Hz
  • 1280 x 1024 @ 50, 60, 75Hz
  • 1280 x 960 @ 50, 60, 75Hz
  • 1280 x 800 @ 50, 60, 75Hz
  • 1280 x 768 @ 50, 60, 75Hz
  • 1280 x 720 @ 50, 60Hz
  • 1152 x 870 @ 75Hz
  • 1152 x 864 @ 60, 75Hz
  • 1024 x 768 @ 50, 60, 70, 72, 75Hz
  • 800 x 600 @ 56, 60, 72, 75Hz
  • 720 x 576 @ 50Hz
  • 720 x 480 @ 60Hz
  • 720 x 400 @ 70Hz
  • 640 x 480 @ 50, 60, 67, 72, 75Hz
  • 640 x 400 @ 60, 70Hz
  • 640 x 350 @ 70Hz
Power Adapter[2] Input Voltage AC 100-240V, 50/60Hz (auto switch)
UE Electronic UES60LCP-200300SPC
Display Area Full Scan (H x V) 341.16 x 193.59 mm (13.43” x 7.62”)
Operating Conditons Temperature 0° C to 40° C (32° F to 104° F)
Humidity 20% to 90% (non-condensing)
Altitude 9,842.5 feet (3 km)
Storage Conditions Temperature -20° C to 60° C (-4° F to 140° F)
Humidity 5% to 90% (non-condensing)
Altitude 40, 000 feet (12.1 km)
Dimensions Physical

(W x H x D)

355.5 x 223.4 x 15.5 mm

(14.5” x 8.79” x 0.61”)

Weight Physical 0.81 kg (1.78 lbs)
Power Saving Modes On[3] 7W (Typical)
Off < 0.3W (Max)
  1. Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display.
  2. Please use the power adapter from ViewSonic® or an authorized source only.
  3. The test condition follows EEI standards.
